The TaeguTec TNMG160408-MF OP1315 is a high-performance, double-sided carbide insert designed for medium to light turning applications. Its 60° triangular shape with a 0.8 mm corner radius ensures excellent chip control and surface finish. The OP1315 grade is a PVD-coated carbide material known for its high hardness, wear resistance, and thermal stability, making it ideal for machining steels, stainless steels, and cast irons.
Key Specifications:
-
Insert Type: Negative Triangular (TNMG)
-
Size: 160408 (16 mm inscribed circle, 4.76 mm thickness)
-
Corner Radius: 0.8 mm
-
Grade: OP1315 (PVD-coated carbide)
-
Coating: PVD (Physical Vapor Deposition)
-
Application: Medium to light turning of steels, stainless steels, and cast irons
-
Feed Rate Range: 0.1 to 0.35 mm/rev
-
Depth of Cut: Up to 2.5 mm
-
Cutting Edge Length: 16.5 mm
-
Insert Thickness: 4.76 mm
